SINGLE-CONDUCTOR ELECTRICAL CONNECTION ENGINEERED FOR FULL DOWNHOLE PRESSURE & TEMPERATURE
Single-Conductor Wet-Mate — Designed for a single-conductor direct electrical stab connection via a 16AWG 1/4" Tubing Encapsulated Cable (TEC)
Validated Under Pressure —Fully qualified for 10 mating cycles (stabs) at a 5,000 psi differential working pressure and temperatures up to 150°C without requiring redress or intervention.
1,000VDC / 5A Capacity — Supports high-voltage power and signal transmission for intelligent wellbore operations, rated explicitly for 1,000VDC and 5A.
Adjustable Landing Signature — Features a precise, customizable deployment profile with a 50,000 lbf landing signature (adjustable in 2,060 lbf increments) and highly controlled shear force thresholds.
Premium 13Cr & FFKM Construction — Built entirely from 80 ksi yield strength 13Cr alloys with a quadruple metal-to-metal and FFKM elastomer splice sealing system. Auxiliary components utilize PEEK, PTFE, and Inconel alloys.
Maintained Electrical Continuity — ield-proven to enable workovers without retrieving the lower completion, maintaining a maximum of 3 Ohms resistance across conductors even after 10 stabs in brine.
Contact our engineering team for specifications, availability,
and field integration support.
